Steam is water which has taken in heat and passed through to the complete vaporization stage. At atmospheric pressure, boiling water and steam have the same temperature - 100°C.

As in practice, a differential pressure is required to cause steam to flow along a pipe, steam is normally supplied at a pressure, some way above atmospheric pressure. Above atmospheric pressure the steam temperature rises; this temperature gradient makes the steam more useful as a heating agent.

This section of the Guide covers all things steam and condensate.

Contents include:

• Steam tables
• Design considerations
• Steam and condensate traps
• Steam separators
• Strainers
• Steam trap checking
• Air venting
• Reduction of heat losses
• Allowance for expansion
• Condensate return
• Handling condensate.
